SCROLL
DOWN TO SEE OTHER DYNA IGNITION SYSTEMS
for Metric Cruiser,
Harley Davidson, ATV, Sportbike and more
|
DYNA 3000 DIGITAL PERFORMANCE IGNITION
SYSTEM |
8 Selectable Advance Curves 8 Selectable
Rev limits (increased
rev limits over stock)
Status LED:
Indicates power-up /
Indicates pickups / Indicates TPS operation /
Indicates MAP sensor operation
Easier Starting Plug & Ride,
5 Min. Install (most
models)
Uses all Factory Sensors Mounts Directly
to Factory Location Uses Factory Coils,
or Dyna Coils Reverse Battery Protection
Retard Mode for
Nitrous or Blower Applications
Dynatek is the performance
leader for quality electronic products in the
motorcycle industry. With the help of top racers
and motorcycle builders around the world, Dynatek
has worked to create the electronic products necessary
to support the modern motorcycle.
|
|
REFERENCE
& DOWNLOADS:
|
|
|
Dyna
Technical Support |
Dyna
Instruction Sheets |
|
|
|
D3K1-1
|
Dyna 3000 Performance Ignition
for 1997-01 Honda Valkyrie GL1500 C STD, CT (Tourer) |
 |
$SAVE
|
|
D3K1-2
|
Dyna 3000 Performance Ignition
3000 for 1997-00 Honda VT1100C2
|
 |
$SAVE
|
|
D3K1-2
|
Dyna 3000 Performance Ignition
for 1997-00 Honda VT1100C2 Shadow Ace |
 |
$SAVE
|
|
D3K1-2
|
Dyna 3000 Performance Ignition
for 1997-98 VT1100C2 Honda Shadow America |
 |
$SAVE
|
|
D3K1-2
|
Dyna
3000 Performance Ignition
for 1998-00 Honda VT1100C3
Shadow Aero up to '98-00 (will NOT fit '01 Aero) |
 |
$SAVE
|
|
D3K1-2
|
Dyna
3000 Performance Ignition
for 1999 VT1100D2 Honda Shadow Ace |
 |
$SAVE
|
|
D3K1-3
|
Dyna
3000 Performance Ignition
1998-01 Honda VT750C, CD, CD2, 750 Shadow Ace |
 |
$SAVE
|
|
D3K1-4
|
Dyna
3000 Performance Ignition
for 1998-00 VT100T Honda Shadow Tourer |
 |
$SAVE
|
|
D3K1-5
|
Dyna
3000 Performance Ignition
for 1994-2002 Honda Magna |
 |
$SAVE
|
|
D3K2-1
|
Dyna
3000 Performance Ignition
for 2000 Kawasaki Vulcan Drifter 800 |
 |
$SAVE
|
|
D3K2-2
|
Dyna
3000 Performance Ignition
for 1999-02 Kawasaki Vulcan 1500G Classic & Nomad (carb only)
|
 |
$SAVE
|
|
D3K3-1
|
Dyna
3000 Performance Ignition
for 1990-95 Suzuki Intruder 1400 |
 |
$SAVE
|
|
D3K3-2
|
Dyna
3000 Performance Ignition
for 1996-01 Suzuki Intruder 1400 |
 |
$SAVE
|
|
D3K3-3
|
Dyna
3000 Performance Ignition
for 1998 Suzuki Intruder 1500 |
 |
$SAVE
|
|
D3K3-4
|
Dyna
3000 Performance Ignition
for 1999-01 Suzuki Intruder 1500 |
 |
$SAVE
|
|
D3K7-1
|
Dyna
3000 Performance Ignition
for 1998-01 Yamaha V-Star 650 |
 |
$SAVE
|
|
D3K7-2
|
Dyna
3000 Performance Ignition
for 1999-01 Yamaha V-Star 1100 |
 |
$SAVE
|
|
D3K7-3
|
Dyna
3000 Performance Ignition
for 1999-03 Yamaha Road Star |
 |
$SAVE
|
|
D3K7-4
|
Dyna
3000 Performance Ignition
for 1996-01 Yamaha Royal Star |
 |
$SAVE
|
|
D3K7-5
|
Dyna
3000 Performance Ignition
for 1999-01 Yamaha Venture |
 |
$SAVE
|
|
D3K7-6
|
Dyna
3000 Performance Ignition
for 1990-01 Yamaha V-MAX |
 |
$SAVE
|
| D3K7-7 |
Dyna
3000 Performance Ignition
for 1985-1989 Yamaha V-MAX |
 |
$SAVE
|
| DC4-1
/ DW800 |
Dyna
3000 High Performance Coils plus Plug Wires
(8mm) for Yamaha Road Star |
 |
$SAVE
|
|
2000TC DIGITAL PERFORMANCE IGNITION SYSTEM
Single-fire, fully programmed performance ignition 16
programmable advance curves in three groups 8 rev limiter
settings in 250 rpm steps from 5750-7250 rpm All functions
offer full digital accuracy Compatible with stock & performance
coils Coil current constantly monitored for full spark energy
Uses all stock sensors and connectors Built-in reverse
battery and spike protection For carbureted 99-03 Twin Cam
88 models
|
|
TC882
|
DYNA 2000 TC88
for 99-03 Twin Cam 88 |
 |
 |
$SAVE
|
|
2000-HDE
PROGRAMMABLE DIGITAL IGNITION SYSTEMS
A
plug-in upgrade to the electronic advance ignition found on late
model Harleys, these ignitions are micro-computer controlled, generating
extremely accurate control over the entire ignition process. Allows
riders to tailor the advance curve and rev limiter to the specific
needs of their particular engine -- four built-in advance curves
cover the needs of stock to highly modified engines over a variety
of operating conditions; four independent rev limiter choices from
6000 to 7500 rpm set the exact protection level needed. DD2000-HD1E8
comes with 8-pin connectors as used on 94 and later Harleys; operates
in single-fire or dual-fire modes. DD2000-HD2E8 comes with
8-pin connectors as used on 94 and later Harleys; operates in dual-fire
mode only. D2000-HD1E8 and DD2000-HD2E8 offer a quick
curve which simulates a mechanical advancer for hot rod motors;
option to use vacuum advance compensation via a VOES switch and
retard mode, which allows selection of ignition retard of 5°,
7° or 10° upon activation of a retard input. DD2000-HD2
is for use with a dual-fire ignition only; it simply plugs right
into your 7-pin stock harness and mounts right in the original ignition
mounting area . DD2000-HD1 comes with a 7-pin connector;
can be used with either one ignition coil firing both cylinders
(dual fire), or with two ignition coils, one firing each cylinder
(single-fire) -- no other ignition offers this flexibility . A separate
tach output wire allows clean tach operation during rev limiting
and when in single-fire mode. A diagnostic LED indicator is included
on the back of the control module to assist trouble shooting and
static timing. Note: Not for fuel-injected models. HDE systems are
not compatible with Dyna "S" systems. Use HD1/HD2 systems
only.
|
|
DD2000-HD1E8
|
DYNA 2000-HDE
Single or dual-fire ignition system (8-pin) |
 |
 |
$SAVE
|
|
DD2000-HD2E8
|
DYNA 2000-HDE
Dual-fire ignition system (8-pin) |
 |
 |
$SAVE
|
|
DD2000-HD1
|
DYNA 2000-HDE
Single or dual-fire ignition system (7-pin) |
 |
 |
$SAVE
|
|
DD2000-HD2
|
DYNA 2000-HDE
Dual-fire ignition system (7-pin) |
 |
$SAVE
|
|
SINGLE-FIRE IGNITION & COIL KITS
Kit
includes Dyna 2000 ignition module & Twin Fire coils. Dyna 2000
ignition has expanded advance curve functionality, a special retard
mode for turbo-charged and nitrous bikes, selection between four
advance curves, a quick curve which simulates a mechanical advancer
for hot rod engines and four independent rev limiter choices (from
6000 to 7500 rpm). Dyna Twin Fire coils incorporate two performance
coils into a single package that is only slightly larger than the
stock coil and mounts easily to the stock mounting bracket; delivers
spark voltage in excess of 30,000 volts with fast rise times and
high energy
|
|
SFK-1
|
DYNA
2000-single-fire ignition & coil kit
For 84-94 Softail/Dyna, 86-93 XL;84-93 FLT; 82-94 FXR |
 |
 |
$SAVE
|
|
SFK-3
|
DYNA
2000-single-fire ignition & coil kit
For 95-99 Softail, 95-98 Dyna, 94-98 XL; 94-98 FLT |
 |
$SAVE
|
|
2000i ELECTRONIC IGNITION
Trouble & hassle-free ignition - fits
in nose cone. Self-contained - entire unit
hides under the cam cover. Single-fire operation for easier cranking
& kicking . Operates in all combinations of single-fire or dual-fire
with single-plug or dual-plug heads. 10 advance curves for different
builds & riding styles. Engine over-rev protection, adjustable
from 6000-7500 rpm. Adjustable timing retard for nitrous & turbo
applications. VOES indicator monitors VOES switch. Built-in tach
driver for activating shift lights, auto-shifters
and other accessories. Easy static timing with built-in timing indicator.
Intelligent over-current/short-circuit protection. Active dwell
control. Over-voltage protected against momentary spikes
For 70-99 carbureted models; 82 and earlier models requires sensor
cup addition, OEM #32402-83 (not for Twin Cam)
|
|
D2Ki-1
|
DYNA
2000i-module only
For 70-99 carbureted modules (except TC)
82 and earlier models requires sensor cup addition |
 |
 |
$SAVE
|
|
D2Ki-2
|
DYNA
2000i-single plug/single fire kit
(includes module & pair of DC3-1
coils) For 70-99 carbureted modules (except TC)
82 and earlier models requires sensor cup addition |
 |
$SAVE
|
|
D2Ki-3
|
DYNA
2000i-dual plug/single fire kit
(includes module & pair of DC1-1
coils) For 70-99 carbureted modules (except TC)
82 and earlier models requires sensor cup addition |
 |
$SAVE
|
|
D2Ki-4
|
DYNA
2000i-dual plug/dual fire kit
(includes module & pair of DC2-1
coils) For 70-99 carbureted modules (except TC)
82 and earlier models requires sensor cup addition |
 |
$SAVE
|
|
D2Ki-5a
|
DYNA
2000i-carbureted single plug/single fire kit
(includes module & DC6-5 Twin
fire 2 miniature coil) For 70-99 carbureted modules (except TC)
82 and earlier models requires sensor cup addition |
 |
$SAVE
|
|
ELECTRONIC PERFORMANCE IGNITION FOR METRIC
CRUISER
Increased
Mid Range Power and Torque. Broad Range Adjustable Rev. Limiter.
Side Stand Safety Interlock Input. Diagnostic LED Indicator Light.
Throttle Position Sensor Input. Ten Different Advance Curves. Increased
Peak Horsepower. Increased Fuel Economy. Digital Tach Output. Improved
Starting. Easy Mounting.
1 Year Warranty Increased Power, Torque and Peak
Horsepower over The Stock Factory Ignition. Larger Gains and Greater
Engine Efficiency When Used with Aftermarket Performance Products.
The DYNA 2000 Makes It All Work Better, Every Time.
|
|
DDK2-10
|
DYNA 2000
for 1994-99 Kawasaki Vulcan "A" Models
|
 |
 |
$SAVE
|
|
DDK2-13
|
DYNA 2000
for 1996-99 Kawasaki 1500 Vulcan D1, D2, E1 Classic
|
 |
$SAVE
|
|
DDK2-14
|
DYNA 2000
for 1999 Kawasaki Vulcan 750
|
 |
$SAVE
|
|
DDK2-15
|
DYNA 2000
for 1995-02 Kawasaki Vulcan 800 & 800 Classic
|
 |
$SAVE
|
|
DYNA
2000 Ignition for Sportbike
The Dyna 2000 Digital Performance Ignition for four cylinder
engines represents a breakthrough in motorcycle ignition flexibility.
The Dyna 2000 system consists of a state of the art microprocessor
controlled ignition module along with an adjustable Dyna dual
sensor crank trigger. For the first time you can actually
set the ignition timing to what you want to maximize engine
performance. A number of different advance curve modes and
a broad range rev limiter let you tailor the ignition to your
needs. * FULLY STATIC TIMEABLE- You can set the timing accurately
to the desired value without having the engine running. *
INDEPENDENT 1/4 2/3 CYLINDER TIMING- The Dyna dual sensor
crank trigger uses one sensor for cylinders 1 & 4 and
the other cylinder for 2 & 3 allowing you to accurately
set the timing for each cylinder pair. * BUILT-IN STATIC TIMING
LIGHT- An LED light built into the Dyna 2000 ignition module
allows you to monitor the crank trigger signal status and
easily set the ignition timing. * FIVE DIFFERENT ADVANCE CURVES-
You can advance slowly to dial out pinging on high compression
motors or bring the advance in quickly on quick revving motors
or select a curve in between to maximize the performance of
your combination. * FOUR DIFFERENT RETARD MODES- The Dyna
2000 is an ideal solution for turbo or nitrous combinations.
* TEST MODE- System check out and troubleshooting is a breeze
with this feature. * SAFETY INTERLOCK INPUT- You can keep
your side stand safety switch functional or hook up a theft
prevention switch, or activate a shift lever kill for road
racing. * BROAD RANGE REV LIMITER- The Dyna 2000 rev limiter
is adjustable from 8500 to 16,000 rpm to let you run in any
range you want. * DIGITAL TACH OUTPUT- Your tachometer will
run smooth and accurate, even at the rev limit. * HIGH ENERGY-
An innovative dwell control scheme maximizes spark energy
all the way to 16,000 rpm! The Dyna 2000 can be used with
2.2 ohm or 3 ohm coils. * EASY MOUNTING- The Dyna 2000 ignition
module has built in frame saddles to make mounting anywhere
a breeze. COMPLETE WIRING HARNESS- The Dyna 2000 kit includes
a complete wiring harness to simplify installation.
LOW COST!-
The Dyna 2000 system in most cases costs less than a stock
ignition box.
|
|
|
| DYNA
2000 FOR HONDA |
|
DDK1-5
|
DYNA 2000
for 1979-83 Honda CB 750, 900, 1100
|
 |
$SAVE
|
|
DDK1-5C*
|
DYNA 2000
for 1979-83 Honda CB 750, 900, 1100 w/coils
|
 |
$SAVE
|
|
DDK1-6
|
DYNA 2000
for 1987-90 Honda CBR 600 F
|
 |
$SAVE
|
|
DDK1-7
|
DYNA 2000
for 1991-94 Honda CBR 600 F2
|
 |
$SAVE
|
|
DDK1-8
|
DYNA 2000
for 1991-94 Honda CBR 600 F3
|
 |
$SAVE
|
|
DDK1-9
|
DYNA 2000
for 1993-97 Honda CBR 900 RR
|
 |
$SAVE
|
|
DDK1-10
|
DYNA 2000
for 1997 Honda CBR 1100XX
|
 |
$SAVE
|
| DYNA
2000 FOR YAMAHA |
|
DDK7-1
|
DYNA 2000
for Yamaha FJ 1100, 1200
|
 |
$SAVE
|
| DYNA
2000 FOR SUZUKI |
| DDK3-2 |
DYNA 2000
for 1977-81 Suzuki GS 550, 750, 850
|
 |
$SAVE
|
| DDK3-2 |
DYNA 2000
for 1977-85 Suzuki GS 1000, 1100, 1150
|
 |
$SAVE
|
| DDK3-2C* |
DYNA 2000
for 1977-85 Suzuki GS 1000, 1100, 1150
|
 |
$SAVE
|
| DDK3-3 |
DYNA 2000
for 1988-95 Suzuki Katana 600, 750, 1100
|
 |
$SAVE
|
| DDK3-3 |
DYNA 2000
for 1996-2000 Suzuki Bandit 1200 S
|
 |
$SAVE
|
| DDK3-3 |
DYNA 2000
for 1986-92 Suzuki GSXR 1100/750 A & OC
|
 |
$SAVE
|
| DDK3-4 |
DYNA 2000
for 1993-97 Suzuki GSXR 1100 WC
|
 |
$SAVE
|
| DDK3-4 |
DYNA 2000
for 1993-97 Suzuki GSXR 750 WC
|
 |
$SAVE
|
|
DDK3-4
|
DYNA 2000
for 1994-97 RF 600, 900
|
 |
$SAVE
|
| DYNA
2000 FOR KAWASAKI |
| DDK2-1 |
DYNA 2000
for 1973-85 Kawasaki KZ 900, 1000, 1100
|
 |
$SAVE
|
| DDK2-1 |
DYNA 2000
for 1981-85 GPZ W/ Modifications 1100
|
 |
$SAVE
|
| DDK2-1C* |
DYNA 2000
for 1973-85 Kawasaki KZ 900, 1000, 1100
|
 |
$SAVE
|
| DDK2-1C* |
DYNA 2000
for 1981-85 GPZ W/ Modifications
|
 |
$SAVE
|
|
DDK2-2
|
DYNA 2000
for 1977-80 Kawasaki KZ 650
|
 |
$SAVE
|
| DDK2-2C |
DYNA 2000
for 1977-80 Kawasaki KZ 650 w/Coils
|
 |
$SAVE
|
|
DDK2-2
|
DYNA 2000
for 1980-84 Kawasaki KZ 750 includes GPZ & Turbo
|
 |
$SAVE
|
| DDK2-2C |
DYNA 2000
for 1980-84 Kawasaki KZ 750 includes GPZ & Turbo w/Coils
|
 |
$SAVE
|
| DDK2-3 |
DYNA 2000
for 1981 Kawasaki GPZ550
|
 |
$SAVE
|
|
DDK2-3C*
|
DYNA 2000
for 1981 Kawasaki GPZ550 w/Coils
|
 |
$SAVE
|
| DDK2-4 |
DYNA 2000
for 1990-97 Kawasaki ZX11 1100
|
 |
$SAVE
|
| DDK2-4 |
DYNA 2000
for 1988-97 Kawasaki ZX10 1000
|
 |
$SAVE
|
| DDK2-4 |
DYNA 2000
for 1986-87 Kawasaki Ninja 1000R
|
 |
$SAVE
|
| DDK2-4 |
DYNA 2000
for 1986-87 Kawasaki Ninja 900R
|
 |
$SAVE
|
| DDK2-7 |
DYNA 2000
for 1991-97 Kawasaki ZX7, ZX7R, ZX7RR
|
 |
$SAVE
|
| DDK2-7 |
DYNA 2000
for 1993-97 Kawasaki ZX9R
|
 |
$SAVE
|
| DDK2-11 |
DYNA 2000
for 1998-2000 Kawasaki ZX6R G!, G2, J1
|
 |
$SAVE
|
| DDK2-12C** |
DYNA 2000
for 1998-2000 Kawasaki ZX9R C1, E1, E2 w/coil
|
 |
$SAVE
|
|
DDK2-17C
|
DYNA 2000
for 1972-1975 Kawasaki H2 750 Triple
|
 |
$SAVE
|
|
Dyna
III hi-performance electronic ignition for BMW and Moto Guzzi
the Dyna 3
high-performance electronic ignition:
eliminates breaker points and condensers,
provides faster starts and extends plug life, is easy to install
with no special tools or wiring, pays for itself by eliminating
ignition tune-ups (the timing and dwell never change), operates
at cool temperatures (no stress to components from engine
heat), is factory tested to 15,000 RPM, and is for use with
coils having 3-ohm primary resistance.
|
|
|
|
DS35-1
|
DYNA
III hi-performance electronic
ignition
for BMW, all single ignition
70-78
|
 |
$SAVE
|
|
DS37-1
|
DYNA
III hi-performance electronic
ignition
for Moto-Guzzi 74 and up
|
 |
$SAVE
|
|
DYNA ATV
FS Programmable Ignition for Quads
The Dyna FS for quads is
our hottest new product this year. Direct Plug in Performance.
As used by winning pro racers worldwide. Now available to
You! Available with features that will let you customize your
quad, and make it the trickest, fastest, baddest one around.
Features Include:
Programmable Timing Curves (4)
Programmable Rev Limits
Increased Spark Energy
Improved Throttle Response
Easier Starting
Programmable RPM Activated Outputs(2) (Can be used
for Nitrous Activation, Shift Light, Auto Shifter, or Boost
Control)
Tach Output
Shift Kill Interrupt(Allows clutchless shifting)
External Curve Selector Switch
Plug-In Module Replacement (Easy Mounting)
|
|
|
| DYNA
FS FOR HONDA ATV |
|
DFS1-10P
|
DYNA
FS programmable ignition
for 1986-1989 Honda TRX400EX Programmable
|
 |
$SAVE
|
|
DFS1-11P
|
DYNA
FS programmable ignition
for 1999-2002 Honda TRX250R Programmable
|
 |
$SAVE
|
| DYNA
FS FOR YAMAHA ATV |
|
DFS7-6P
|
DYNA
FS programmable ignition
for 1997-2003 Yamaha YZF350 Programmable
|
 |
$SAVE
|
|
DFS7-7P
|
DYNA
FS programmable ignition
for 1995-1996 Yamaha YZF350 Programmable
|
 |
$SAVE
|
|
DFS7-8P
|
DYNA
FS programmable ignition
for 1987-1994 Yamaha YZF350 Programmable
|
 |
$SAVE
|
|
DFS7-9P
|
DYNA
FS programmable ignition
for 1997-01 Yamaha YFM350X Warrior Programmable
|
 |
$SAVE
|
|
DFS7-10P
|
DYNA
FS programmable ignition
for 2001 Yamaha YFM660R Raptor Programmable
|
 |
$SAVE
|
|
DFS7-11P
|
DYNA
FS programmable ignition
for 2002 Yamaha YFM660R Raptor Programmable
|
 |
$SAVE
|
| DYNA
FS FOR SUZUKI ATV |
|
DFS3-9P
|
DYNA
FS programmable ignition
for 2003 LTZ400 Suzuki Quadsport Programmable
|
 |
$SAVE
|
| DYNA
FS FOR KAWASAKI ATV |
|
DFS2-11P
|
DYNA
FS programmable ignition
for 2003 KFX400 Kawasaki Quad Programmable
|
 |
$SAVE
|
| PROGRAMMING
KIT |
|
DFSPK-1
|
DYNA
FS programmable ignition
Programming Kit
|
 |
$SAVE
|
|
DYNA
S self contained electronic ignition for Sportbikes
The Dyna S Digital Performance Ignition is
totally self-contained for easy installation. All components
fit under the point cover, replacing the original points.
Dyna S utilizes all the time-proven Dyna III circuitry but
comes in a smaller, condensed package. Use with coils having
3-ohm primary resistance.
|
|
|
|
DS1-2
|
DYNA S self contained
electronic ignition
for Honda 500, 550, 750 4 cylinder 69-78
|
 |
$SAVE
|
|
DS2-1
|
DYNA
S self contained electronic ignition
for Kawasaki 900, 1000, 1100 4 cylinder 73-85
|
 |
$SAVE
|
|
DS2-2
|
DYNA
S self contained electronic ignition
for Kawasaki KZ550, 650, 750 4 cylinder (all)
|
 |
$SAVE
|
|
DS3-2
|
DYNA
S self contained electronic ignition
for Suzuki 550, 750, 850, 1000, 1100 4 cylinder (ND) 77-81
|
 |
$SAVE
|
|
DS1-3
|
DYNA
S self contained electronic ignition
for GL1000 75-79
|
 |
$SAVE
|
|
 |
